VLAN CONFIGURATION



 CISCO SWITCHECLI INTERFACE HIS 3 MODE

1.USER MODE
                            switch>
2. ENABLE MODE
                                    switch#
3. CONFIGURATION TERMINAL MODE
                                                                           switch(config)#

_________________________

WHEN FIRST TIME ROUTER HIS OPEN THE FIST MODE HIS APPEARS

   switch>   AND WHEN TO ENABLE MODE TO ENTER    switch> enable

SEE  TO ENABLE MODE    switch#

AND WHEN TO CONFIGURATION MODE TO ENTER  switch# config t

AND SEE THE CONFIGURATION MDE  switch(config)#

_______________________

THE PURPOSE OF ENABLE MODE IS ALL THE CONFIGURATION YOU PERFORMS A SWITCH TO SEE IT AND ANY IP PING IN ENABLE MODE
AND CHECK COMMUNICATION.

THE PURPOSE OF CONFIGURATION TERMINAL MODE ALL THE PROTOCOLS AND CONFIGURATION POERFORMED HIS MODE.

_________________________

 WHAT IS VLAN

DEVIDED SINGLE BROADCAST DOMAIN INTO LOGICALLY  MULTYPAL BROADCAST DOMAINS IS CALLED VLAN.

THE VIRTUAL LOCAL AREA NATWORK IS LAN CONFIGURED NOT BY PHYSICAL WIRING LIKE CONVENTIONAL LAN BUT IS CONFIGURED BY SWITCHES.

THERE ARE 32 BITS IN A VLAN HEADER. THIS IS BROKEN DOWN AS FOLLOWS:

TPID (TAG PROTOCOL IDENTIFIER): 16 BITS

PCP (PRIORITY CODE POINT): 3 BITS

DEI (DROP ELIGIBLE INDICATOR): 1 BIT

VID (VLAN IDENTIFIER): 12 BITS



BENEFIT OF VLAN
1. SECURITY PURPOSE.

2. CONTROLL BROADCASTING.

ADDVANTAGES OF VLAN

1. REDUCTION IN COST

2. SAVING OF TIME REQURID FOR REWIRING

3. VLAN PROVIDES ADDITIONAL SECURITY

4. THE MESSAGE BROADCAST INONE GROUP CANNOT BE LISTEN BY ANOTHER GROUPS.

________________________________________

CONFIGURATION VLAN

FIRST STEP

GO TO SWITCH CLI INTERFACE

WE WILL  CONFIGURED VLAN THIS BASED ON YOUR COMPUTER PORTS ATTACHED ON A SWITCH.

WE WILL CONFIGURED VLAN'S

VLAN 10      NAME IT   PORTS ASSIGN inter fa0/1-3

VLAN 20   NAME  HR  PORT ASSIGN  inter fa0/4-7

VLAN 30   NAME SALE   PORT ASSIGN   inter fa0/8-10

SECOND STEP

COMMUNICATION BETWEEN VLAN 10 VLAN 20 AND VLAN 30

__________________________________

FIRST STEP


CONFIGURE VLAN COMMANDS

GO TO SWITCH CONFIGURATION MODE

Switch(config)#  Vlan 10
Switch(config)#  name it
Switch(config)#  vlan 20
Switch(config)#   name hr
Switch(config)#   vlan 30
Switch(config)#   name sale
Switch(config)#  inter range fa0/1-3
Switch(config-if-range)#  switchport mode access
Switch(config-if-range)#   switchport access vlan 10
Switch(config-if-range)#   inter range fa0/4-7
Switch(config-if-range)#   switchport mode access
Switch(config-if-range)#    switchport access vlan 20
Switch(config-if-range)#   inter range fa0/8-10
Switch(config-if-range)#    switchport mode access
Switch(config-if-range)#    switchport access vlan 30

SEE THE VLAN GO TO SWITCH ENABLE MODE AND ENTER THE COMMAND

Switch# show vlan


TO SEE CONFIGURED THE VLAN'S. BUT DIFFERENT VLAN'S PC CANNOT COMMINICATION BETWEEN THEM.

GO TO  VLAN 30  LAPTOP AND CLICK DESKTOP AND GO TO COMMAND PORMOT

WE PING THE VLAN 10  PC AND VLAN 30 LAPTOP  IP IS 192.168.1.2 AND 192.168.1.9

SO ENTER THE COMMAND

 C:\> PING 192.168.1.2

SECOND STEP

COMMUNICATION BETWEEN VLAN 10 VLAN 20 AND VLAN 30
AGEN GO TO SWITCH CLI INTERFACE AND ENTER THE COMMAND.

Switch(config)#  inter range fa0/1-10

Switch(config-if-range)#  switchport mode trunk


AND AGAIN PING SAME VLAN 10 AND VLAN 30 DEVICES


 C:\> PING 192.168.1.2



COMPLETE THE ALL STEPS AND DONE THE CONFIGURATION.
